Isolated DC-DC Converter 30W ±12V ±1.25A Output 18-75Vin Positive Logic Remote On/Off

Features

  • Efficiency up to 90%
  • Fixed Switching Frequency
  • Regulated Outputs
  • Positive Logic Remote On/Off
  • Low No Load Power Consumption
  • Fully Protected (OTP/OCP/OVP/UVLO)
  • 1500Vdc I/O Isolation
  • No Tantalum Capacitor Inside
  • Five-Sided Shielded Metal Case
  • Meets Industrial Standard 1"x1”x0.4”
  • UL62368-1 Approval
  • CB Test Certificate IEC62368-1
  • 5000m Operating Altitude

Overview

Isolated DC-DC Converter 30W ±12V ±1.25A Output with 4:1 Input (18-75Vin) and features positive logic Remote On/Off.

Product Identification

Type:Isolated
Additional Feature:Positive Logic Remote ON/OFF
Product Type:DC-DC Converter SMPS
Manufacturer Series:EC5SBW

Compliance

Agency Approvals:UL, CUL, CB, CE, UKCA, EN, IEC

Dimensions & Appearance

Color:Black
Height:0.40 in.
Width:1 in.
Length:1 in.

Operating conditions

Maximum Operating Temperature:105°C
Minimum Operating Temperature:-40°C

Input

Input Voltage Range:18 VDC to 75 VDC
Input Voltage:48 VDC
Maximum Input Current:0.710 A

Output

Number of Outputs:2
Additional Output Voltages (VDC):-12 VDC
Output Voltage:12 VDC
Output Connector Type:PC Pins
Output Current:±1.25 A

Features

Isolation Voltage:1500V
Pins:6
Efficiency:89%
Power Rating:30 W
,
