CMOS UV EEPROM 4MBit (256K x 16) 120ns 5V DIP-40
Features
- Density: 4 MBit
- Organization: 256K x 16
- Speed: 120ns
- Voltage: 5V
- Packaging: DIP-40
Dimensions & Appearance
Mounting:Through Hole
Operating conditions
Minimum Operating Temperature:0°C
Maximum Operating Temperature:70°C
Packaging
Package:DIP-40
Input
Input Voltage:5V
Output
Output Enable Access Time:60ns
Features
Reprogramming Technique:UV
Screening Level:Commercial
Programming Voltage:12.5V
Memory Density:4Mbit
Maximum Random Access Time:120ns
Maximum Operating Current:70mA
Organization:256Kx16
