Wall-Mount Green Adapter 48VDC 0.63A 30W 2.1mm Plug with Fixed Euro CEE 7/16 Plug

Features

  • MEAN WELL Patent Application Number: 202330347779.4
  • Fixed Euro CEE 7/16 Plug
  • Global certificates in multiple fields: (ITE 62368-1, Medical 60601-1, Household 60335-1, Industrial 61558-1/-2-16)
  • Universal AC Input, full range
  • Ultra Slim (30 mm)
  • No load power consumption <0.075 W
  • Energy efficiency Level VI
  • Class II power (no earth pin)
  • Protections: Short circuit, overload, over voltage
  • Pass LPS
  • Extremely low leakage current: <100 µA
  • -30°C to +70°C wide range working temperature
  • Various DC plug adapter accessories are available
  • 3-year warranty

Applications

  • Consumer electronic devices
  • Telecommunication devices
  • Office facilities
  • Industrial equipment
  • Medical devices
  • Household devices

Overview

NGE30 is a highly reliable 30W wall-mounted single-output green adapter series which is compact and easy for carry. NGE30 is a class II power unit (no FG), accepting a wide input range from 80 VAC to 264 VAC so it can satisfy the demands for various types of electrical devices.

With working efficiency up to 91.5% and an extremely low no-load power consumption below 0.075W, the NGE30 is compliant with the latest USA energy regulations EISA 2007/DoE, Canada NRCan, Australia and New Zealand MEPS, EU ErP and CoC version 5. The ultimate feature allows the adapter to save energy during operation and standby modes. The entire series is approved for ITE, medical, household and industrial appliance safety regulations. Additionally, it adopts the 94V-0 flame retardant plastic case so it can effectively prevent users from electric hazard.

Product Identification

Product Type:Switching SMPS Green Adapter
Manufacturer Series:NGE30

Compliance

Agency Approvals:UL, CUL, TUV, CB, CE, FCC, EN, EAC, C-TICK, PSE, DEKRA, CCC, RCM

Dimensions & Appearance

Style:Fixed Euro Plug
Color:Black
Width:1.18 in.
Height:2.56 in.
Length:2.44 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Connector:CEE 7/16
Input Voltage:80 VAC to 264 VAC
Maximum Input Current:1 A

Output

Number of Outputs:1
Output Cord Length:5 ft.
Output Connector Diameters:2.1mm x 5.5mm
Output Connector Type:Cylindrical Female
Output Voltage:48 VDC
Output Current:0.63 A

Features

Polarity:Center Positive
Product Note:Level VI
AC Power Cord:N/A
Efficiency:91.5%
Power Rating:30 W
,
