Wall-Mount Green Adapter 24VDC 1250mA 30W 2.1mm Plug with Foldable NEMA 1-15P
Product Identification
Product Type:Switching SMPS Green Adapter
Manufacturer Series:NGE30
Compliance
Agency Approvals:UL, CUL, TUV, CB, CE, FCC, EN, EAC, C-TICK, PSE, DEKRA, CCC, RCM
Dimensions & Appearance
Style:Fixed USA Plug
Color:Black
Width:1.18 in.
Height:2.56 in.
Length:2.44 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Connector:NEMA 1-15P
Input Voltage:80 VAC to 264 VAC
Maximum Input Current:1 A
Output
Number of Outputs:1
Output Cord Length:5 ft.
Output Connector Diameters:2.1mm x 5.5mm
Output Connector Type:Cylindrical Female
Output Voltage:24 VDC
Output Current:1.25 A
Features
Polarity:Center Positive
Product Note:Level VI
AC Power Cord:N/A
Efficiency:88.5%
Power Rating:30 W
