Wall-Mount Green Adapter 24VDC 0.625A 15W 2.1mm Plug with Fixed CEE 7/16 Plug
Features
- MEAN WELL Patent Application Number: 202330347779.4
- Fixed CEE 7/16 Plug
- Global certificates in multiple fields: (ITE 62368-1, Medical 60601-1, Household 60335-1, Industrial 61558-1/-2-16)
- Universal AC Input, full range
- Ultra Slim (28 mm)
- No load power consumption <0.075 W
- Energy efficiency Level VI
- Class II power (no earth pin)
- Protections: Short circuit, overload, over voltage
- Pass LPS
- Extremely low leakage current: <100 µA
- -30°C to +70°C wide range working temperature
- Various DC plug adapter accessories are available
- 3-year warranty
Applications
- Consumer electronic devices
- Telecommunication devices
- Office facilities
- Industrial equipment
- Medical devices
- Household devices
Overview
NGE12 is a highly reliable 12W wall-mounted single-output green adapter series which is compact and easy for carry. NGE12 is a class II power unit (no FG), accepting a wide input range from 80 VAC to 264 VAC so it can satisfy the demands for various types of electrical devices.
With working efficiency up to 88.5% and an extremely low no-load power consumption below 0.075W, the NGE12 is compliant with the latest USA energy regulations EISA 2007/DoE, Canada NRCan, Australia and New Zealand MEPS, EU ErP and CoC version 5. The ultimate feature allows the adapter to save energy during operation and standby modes. The entire series is approved for ITE, medical, household and industrial appliance safety regulations. Additionally, it adopts the 94V-0 flame retardant plastic case so it can effectively prevent users from electric hazard.
