UTS3015T+ 1.5GHz Performance-Series Spectrum Analyzer with Tracking Generator

Features

• Freq: 9kHz-1.5GHz; RBW: 1Hz-1MHz; DANL: -161dBm/Hz; Phase noise: <-98dBc/Hz; Full amplitude accuracy: <0.7dB; Display: 10.1 inch touch screen with tracking generator
• Display Size: 10.1 in.
• Warranty: 3 years
• Interface: T Gen, USB, LAN, 10MHz In/Out, Ext Ref In, Trg In, HDMI, audio
• Prop65: No
• Reach: No

Overview

The UNI-Trend UTS3015T+ Performance-Series Spectrum Analyzer includes a tracking generator and is an affordable 1.5GHz signal analyzer for EMI pre-compliance testing and a variety of other applications. Offers VSWR reflection measurement capability.

Technical Specifications

• Accessories Universal Accessories: Power cord, USB2.0 printing cable
• Packing List: English download guide, multi-language safety manual, calibration report (COC)
• Software Downloads
• T Screen: Yes
• Frequency Range: 9kHz-1.5GHz
• RBW: 1Hz-1MHz
• DANL: -161dBm/Hz
• Tracking Generator: Included
• Sweep Points: 10,001
• Traces: 4
• Phase Noise: -98 dBc/Hz @10kHz
