Unshielded Wirewound Inductor 330uH 62mA 28 Ohm Axial

Specifications

  • Type: Wirewound
  • Material - Core: Ferrite
  • Inductance: 330 µH
  • Tolerance: ±10%
  • Current Rating (Amps): 62 mA
  • Shielding: Unshielded
  • DC Resistance (DCR): 28 Ohm Max
  • Q @ Freq: 30 @ 790 kHz
  • Frequency - Self Resonant: 4 MHz
  • Operating Temperature: -55°C to 105°C
  • Inductance Frequency - Test: 790 kHz
  • Mounting Type: Through Hole
  • Package: Axial
  • Size: 0.120" Dia x 0.300" L (3.05 mm x 7.62 mm)
  • Base Number: 8230

,
