Unshielded Wirewound Inductor 150uH 85mA 15 Ohm Axial

Specifications

  • Type: Wirewound
  • Material - Core: Ferrite
  • Inductance: 150 µH
  • Tolerance: ±10%
  • Current Rating (Amps): 85 mA
  • Shielding: Unshielded
  • DC Resistance (DCR): 15 Ohm Max
  • Q @ Freq: 30 @ 790 kHz
  • Frequency - Self Resonant: 11 MHz
  • Operating Temperature: -55°C to 105°C
  • Inductance Frequency - Test: 790 kHz
  • Mounting Type: Through Hole
  • Package: Axial
  • Size: 0.120" Dia x 0.300" L (3.05 mm x 7.62 mm)
  • Base Number: 8230

Product Identification

Manufacturer Series:8230

Features

Lead Style:Axial
Core Material:Ferrite
Tolerance:10%
Technology:Wirewound
Minimum Quality Factor:30@790KHz
Maximum Self Resonant Frequency:11 MHz
Inductance:150 uH
Current Rating:85 mA
Maximum DC Resistance:15 Ohms
,
