Unshielded Wirewound Inductor 10uH 10% 1.4A 220 mOhm Axial

Specifications

  • Series: LBC
  • Type: Wirewound
  • Material - Core: Ferrite
  • Inductance: 10 µH
  • Tolerance: ±10%
  • Current Rating (Amps): 1.4 A (1400 mA)
  • Current - Saturation: n/a
  • Shielding: Unshielded
  • DC Resistance (DCR): 220 mOhm Max
  • Q @ Freq: 60 @ 2.52 MHz
  • Frequency - Self Resonant: 60 MHz
  • Ratings: n/a
  • Operating Temperature: -55°C to 125°C
  • Inductance Frequency - Test: 1 MHz
  • Mounting Type: Through Hole
  • Package: Axial
  • Size: 0.205" Dia x 0.472"L (5.20 mm x 12.00)

,
