Resistor Trimmer 200 Ohm 10% 3/4 Watt 15 Turn 2.36mm Pin Through Hole

Features

  • Resistance: 200 Ohm
  • Tolerance: 10%
  • Power: 3/4 Watt
  • 15 Turn

    • Product Identification

    Family:P
    Product Type:Trimmer
    Manufacturer Series:3006

    Dimensions & Appearance

    Mounting:Through Hole
    Width:4.83 mm
    Height:6.35 mm
    Length:20.57 mm
    Shaft Diameter:2.36 mm

    Operating conditions

    Maximum Operating Temperature:125°C
    Minimum Operating Temperature:-55°C

    Features

    Taper:Linear
    Resistive Element Material:Cermet
    Actuator Orientation:Side
    Number of Turns:20
    Tolerance:10%
    Temperature Coefficient:100 ppm/°C
    Technology:Sealed
    Resistance (Ohm):200
    Power Rating:0.75 W
    Termination Style:Pins
    Actuator Type:Side Slot
    Resistance:200 Ohm
    ,
