TRANSISTOR, IRL520N, N CHANNEL POWER MOSFET, 100V, 10A, TO-220
For more about Transistors, click here.
Product Identification
Family:IRL5
Product Type:MOSFET
Dimensions & Appearance
Mounting:Through Hole
Length:10.28 mm
Width:4.57 mm
Height:9.02 mm
Operating conditions
Maximum Operating Temperature:175°C
Minimum Operating Temperature:-55°C
Packaging
Packaging:Bulk
Package:TO-220-3
Input
Typical Input Capacitance @ Vds:490pf@24V
Output
Output Power:60W
Features
Number of Elements per Chip:1
Channel Type:N
Maximum Gate Source Voltage:±10V
Transistor Polarity:N
Typical Gate Charge @ Vgs:12nC@5V
Pins:3
Channel Mode:N-Channel Enhancement
Category:Power MOSFET
Typical Turn-Off Delay Time:9.8ns
Maximum Drain Source Voltage:100 V
Maximum Reverse Current:25uA
Maximum Continuous Drain Current:9.2 A
Peak Non-Repetitive Surge Current:36A
Peak Reverse Recovery Time:64ns
Maximum Forward Current:9.2A
Repetitive Peak Reverse Voltage:100VDC
Maximum Drain Source Resistance:0.27 Ohms@5V
Typical Fall Time:27ns
Typical Turn-On Delay Time:64ns
Power Dissipation:60 W
Typical Rise Time:64ns
Maximum Forward Voltage:100VDC
Configuration:Single
