Toggle Switch SPDT ON-ON 0.4VA 20V Right Angle SMT Gull Wing

Specifications

  • Contact form: SPDT
  • Switch Function: ON-ON
  • Mounting Type: Surface Mount, Right Angle
  • Termination Style: Screw Terminals
  • Actuator Type: Standard Round
  • Actuator Length: 12 mm
  • Bushing Type: 15/32-32
  • Current Rating: 0.4 VA @ 20 V AC/DC
  • Body Color: White
  • Lever Color: Chrome
  • Epoxy Sealed Terminals

Compliance

RoHS Status:Undefined

Dimensions & Appearance

Body Material:Nylon 4/6
Mounting Hole:0.15 in.
Body Orientation:Right Angle
Body Color:White
Mounting Style:Panel, Rear
Depth:0.43 in.
Height:0.20 in.
Width:0.32 in.
Length:0.59 in.

Features

Actuator Material:Brass
Seal Description:Epoxy
Number of Positions:2
Pins:3
Bushing Type:Unthreaded
Lead Spacing A (inch):0.1
Electrical Life:30,000 Cycles
Seal Location:Terminals
Minimum Insulation Resistance:1000MOhm
Maximum Contact Resistance:20mOhm
Dielectric Strength:1500Vrms
Power Rating:0.4 VA
Contact Plating:Gold Over Nickel
UL Flammability Code:N/A
Switch Function:ON-ON
Contact Rating:0.4VA @ 20VAC/DC
Color - Actuator/Cap:Chrome
Actuator Length:0.24 in.
Termination Style:Gull Wing (SMT)
IP Rating:N/A
Contact Form:SPDT
Thread Size:N/A
Voltage Rating:20 VAC, 20 VDC
Actuator Type:Round
Current Rating:N/A
,
