Time Delay Single Shot 0.05sec - 100 Hours 24-240VAC & 12-125VDC 10A DPDT

Features

  • Family: TR-6
  • Function: Single Shot (Switch Trigger)
  • Output Configuration: DPDT
  • Input Voltage: 24-240V AC & 12-125V DC (except 606)
  • Function: SINGLE SHOT
  • Function Name: Single-Shot
  • Timing: PROGRAMMABLE
  • Timing Range: 0.05 SECONDS - 100 HOURS
  • Input: 24-240V AC & 12-125V DC
  • Output: 10A DPDT
  • Voltage Tolerance: AC Operation: 20.4 - 264V at 50/60Hz; DC Operation: 10.2 - 137.5V
  • Insulation Voltage: 2,000 volts
  • Load Burden: Maximum of 3VA for all voltages
  • Output Contacts: 10A @ 240V AC/30V DC, 1/2HP @ 120/240V AC (N.O.), 1/3HP @ 120/240V AC (N.C.), B300 & R300 (N.O.), AC15 & DC13
  • Life: Mechanical: 10,000,000 operations; Full Load: 100,000 operations
  • Temperature: -28° to 65°C (-18° to 149°F)
  • Reset Time: Functions Triggered with Input Voltage: 0.1 Seconds; Functions Triggered with Control Switch: 0.04 Seconds
  • Start-up Time: 0.05 Seconds
  • Repeat Accuracy (Constant Voltage and Temperature): +0.1% or +50ms, whichever is greater
  • Setting Accuracy: Maximum Setting (Adjustable): +5%, -0%; Minimum Setting (Adjustable): +0%, -50%

Overview

Upon application of input voltage, the time delay (t) begins. At the end of the time delay (t), the output is energized. Input voltage must be removed to reset the time delay relay & de-energize the output.

,
