Switching Power Supply Low Profile AC/DC 25.2W 12V 2.1A Screw Terminals IP20 DIN-Rail Mounting 52x91x63mm Plastic Housing

Features

  • Switching Power Supply
  • Low Profile
  • AC/DC
  • 25.2W
  • 12V
  • 2.1A
  • Screw Terminals
  • IP20
  • DIN-Rail Mounting
  • Over-load
  • Over-voltage and Short-circuit Protections
  • 52x91x63mm plastic housing

Overview

Switching Power Supply, Low Profile, AC/DC, 25.2W, 12V, 2.1A, Screw Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 52x91x63mm plastic housing

Product Identification

Manufacturer Series:730
Product Type:Single Phase DC Power Supply

Compliance

Agency Approvals: CE, CUL, EN, UL

Dimensions & Appearance

Color:White
Depth:2.50 in.
Width:2.70 in.
Height:3.60 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:100 VAC to 240 VAC
Maximum Input Current:0.9 A

Output

Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Output Current:2.10 A

Features

PFC Function:No
Low Power Source (LPS):No
Minimum Isolation Voltage:4000V
Efficiency:86%
Power Rating:30 W
,
