Switching Power Supply Low Profile AC/DC 15W 12V 1.25A Screw Terminals IP20 DIN-Rail Mounting 18x91x63mm Plastic Housing
Features
- Switching Power Supply
- Low Profile
- AC/DC
- 15W
- 12V
- 1.25A
- Screw Terminals
- IP20
- DIN-Rail Mounting
- Over-load
- Over-voltage and Short-circuit Protections
- 18x91x63mm plastic housing
Overview
Switching Power Supply, Low Profile, AC/DC, 15W, 12V, 1.25A, Screw Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 18x91x63mm plastic housing
Product Identification
Product Type:Single Phase DC Power Supply
Manufacturer Series:730
Compliance
Agency Approvals: CE, CUL, EN, UL
Dimensions & Appearance
Color:White
Depth:2.50 in.
Width:2.70 in.
Height:3.60 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:100 VAC to 240 VAC
Maximum Input Current:0.45 A
Output
Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Output Current:1.25 A
Features
PFC Function:No
Low Power Source (LPS):No
Minimum Isolation Voltage:4000V
Efficiency:83%
Power Rating:15 W
