Switching Power Supply High Compact AC/DC 480W 48V Screw Terminals IP20 DIN-Rail Mounting 70x124x127.2mm Metallic Housing

Features

  • Switching Power Supply
  • High Compact
  • AC/DC
  • 480W
  • 48V
  • Screw Terminals
  • IP20
  • DIN-Rail Mounting
  • Over-load
  • Over-voltage
  • Short-circuit and Over-temperature Protections
  • 70x124x127.2mm metallic housing

Overview

Switching Power Supply, High Compact, AC/DC, 480W, 48V, Screw Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage, Short-circuit and Over-temperature Protections, 70x124x127.2mm metallic housing

Product Identification

Product Type:Switching Power Supply
Manufacturer Series:730

Compliance

Agency Approvals: CE, CUL, EN, UL

Dimensions & Appearance

Color:Silver
Depth:5 in.
Width:2.76 in.
Height:4.90 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:7 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Output Current:10 A

Features

Low Power Source (LPS):No
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:93.8%
Power Rating:480 W
,
