Switching Desktop Power Adapter 200W 19V 10.5A DIN-4 DC Plug C8 Inlet Black UL
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:YS200
Product Type:Switching Desktop Power Adapter
Compliance
Agency Approvals: CB, CCC, CE, C-TICK, CUL, EAC, EN, FCC, ICC, PSE, TUV, UKCA, UL
Dimensions & Appearance
Style:Desktop
Color:Black
Height:1.85 in.
Width:3.86 in.
Length:7.72 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:50 Hz to 60 Hz
Input Voltage:85 VAC to 265 VAC
Maximum Input Current:2.5 A
Output
Number of Outputs:1
Output Connector Diameters:DIN-4 Male
Output Connector Type:DIN-4
Output Voltage (Channel 1):19 VDC
Output Voltage:19 VDC
Additional Output Voltages (VDC):N/A
Output Current (Channel 1):10.5 A
Output Current:10.5 A
Features
Minimum Isolation Voltage:3000V
Product Note:Level VI
AC Power Cord:NOT INCLUDED, RECOMMEND 189587
Efficiency:91%
Power Rating:200W
