Switching Desktop Power Adapter 150W 24V 6.25A DIN-4 Plug C6 Inlet Black UL
Product Identification
Type:Auto Switching SMPS
Product Type:Switching Desktop Power Adapter
Manufacturer Series:YS125
Compliance
Agency Approvals: CB, CCC, CE, C-TICK, CUL, EAC, EN, FCC, ICC, PSE, TUV, UKCA, UL
Dimensions & Appearance
Style:Desktop
Color:Black
Height:1.85 in.
Width:3.86 in.
Length:7.72 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:50 Hz to 60 Hz
Input Voltage:85 VAC to 265 VAC
Maximum Input Current:1.5 A
Output
Number of Outputs:1
Output Connector Diameters:DIN-4 Male
Output Connector Type:DIN-4
Output Voltage (Channel 1):24 VDC
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current (Channel 1):6.25 A
Output Current:6.25 A
Features
Minimum Isolation Voltage:3000V
Product Note:Level VI
AC Power Cord:NOT INCLUDED, RECOMMEND 2292503
Efficiency:93%
Power Rating:150W
