SSA3032X-R Real-Time Spectrum Analyzers 3.2 GHz

Key Features

  • Frequency Range: 9 kHz~3.2 GHz
  • Resolution Bandwidth (RBW): 1 Hz~3 MHz
  • Phase Noise: <-98 dBc/Hz
  • Total Amplitude Accuracy: < 0.7 dB
  • Display Average Noise Level (DANL): -165 dBm/Hz
  • Spectrum Analyzer Frequency Range from 9 kHz up to 3.2 GHz
  • VNA and DTF included
  • -165 dBm/Hz Displayed Average Noise Level (Typ.)
  • -98 dBc/Hz.@10 kHz Offset Phase Noise (1 GHz, Typ.)
  • Level Measurement Uncertainty < 0.7 dB (Typ.)
  • 1 Hz Minimum Resolution Bandwidth (RBW)
  • Preamplifier and Tracking Generator Standard
  • Vector Network Analyzer Mode Standard
  • Distance to Fault Mode Standard
  • Up to 40 MHz Real Time Analysis Bandwidth
  • 100% POI 7.20 µs, Dynamic Range 60 dB
  • Multi-view for Density, Spectrogram, PvT, and multi trigger and FMT
  • 10.1 inch Multi-Touch Screen, Mouse and Keyboard supported
  • Web Browser Remote Control on PC and Mobile Terminals and File Operation

    Support and Resources

    Upgrade Options

    • Advanced Measurement Kit
    • "EMI Filter and Quasi Peak Detector, EMI Receiver Mode in EasySpectrum Software"
    • Analog Modulation Analysis: AM, FM
    • Digital Modulation Analysis: ASK, FSK, MSK, PSK, QAM
    • 40 MHz Real-Time BandWidth

    • Product Identification

    Additional Feature:10.1" WVGA Display
    Product Type:Spectrum Analyzer

    Compliance

    RoHS Status:ROHS Compliant

    Dimensions & Appearance

    Style:Benchtop

    Features

    Communication Protocol:USB host, USB device, LAN
    Frequency Range:9 kHz to 3.2 GHz
    ,
