DC-to-AC Solid State Relay

Designed for the appliance and temperature control markets, these relays are also well suited for automotive load management.

Features:

  • Control voltage: 3-32VDC
  • Contact form: SPST
  • Contact voltage: 240VAC
  • Contact current: 10A
  • Size: 1.7"L x 1.1"W x 2.3"H
  • 4-pin package
  • Terminal type: Screw terminal
  • Built-in heat sink
  • Agency approvals: UL

Product Identification

Family:ESR
Product Type:DC/AC Solid State Relay

Dimensions & Appearance

Height:27.1 mm
Width:43 mm
Length:57 mm

Features

Pins:4
Control Voltage:3 VDC to 32 VDC
I/O Isolation Voltage:5300V
Contact Current:10 A
Terminal Type:Screw Terminal
Contact Voltage:240 VAC
Contact Form:SPST
,
