SNA5002A Vector Network Analyzer 4.5 GHz 2 Ports

SIGLENT SNA5000A Vector Network Analyzers (VNAs) have a frequency range of 9 kHz to 4.5 GHz, with 2 ports. Designed to give you instant insight into scattering, differential, and time-domain measurements. Siglent VNAs are effective instrumentation for determining the Q-factor, bandwidth, and insertion loss filters and feature impedance conversion, movement of measurement plane, limit testing, ripple test, fixture simulation, and adapter removal/insertion adjustments. There are five sweep types: Linear-Frequency, Log-Frequency, Power-Sweep, CW-Time, and Segment-Sweep mode. SNA5000A VNAs also support scattering-parameter correction of SOLT, SOLR, TRL, Response, and Enhanced Response for increased flexibility in R&D and manufacturing applications.

Key Features

• Frequency Range: 9 kHz~4.5 GHz
• Ports: 2
• Dynamic Range: 125 dB
• Trace Noise: 0.003 dB rms,0.03° rms
• Range of Output: -55 ~ +10 dBm
• Frequency resolution: 1 Hz
• Level resolution: 0.05 dB
• Range of IFBW: 10 Hz~3 MHz
• Supports Bias-Tees
• Interface: LAN, USB Device, USB Host(USB-GPIB)
• Remote control: SCPI/Labview/IVI based on USB-TMC/VXI-11/Socket/Telnet/WebServer
• 12.1-inch touch screen
• Video output: HDMI

Support and Resources

• Software (off-site)
• Firmware (off-site)
• Drivers (off-site)
• Scripts and Others (off-site)
• Documents (off-site)
• Operating Tips (off-site)
• Videos (off-site)

Upgrade Options

• High Performance Reference Source
• Time Domain Analysis (software)
• Enhanced Time-Domain analysis (software)?Buy TDR will get also TDA for free)
• Spectrum Analyzer (software)
