SMD Package DC-DC Unregulated Converter 1W 18V 5-55mA

MEAN WELL

Jameco Part #:

Manufacturer #:

Primary datasheet

Non Cancelable

Non Returnable

Product Price:

$3.850

In Stock: 0

Quantity	Unit Price	You Save	Discount
1+	$3.850	-	-
10+	$3.550	0.30	7.79%
100+	$3.250	0.60	15.58%

Features

SMD package with industry standard pinout
Operating temperature range -40 to +100°C
High efficiency up to 83%
2000V DC I/O isolation
Low cost
3 year warranty

Applications

Telecom/datacom system
Wireless network
Industrial control facility
Instrument
Analyzer
Detector
Data switch

Overview

SBTN01-N series is a 1W isolated and unregulated module type DC-DC converter with SMD package. It features international standard pins, a high efficiency up to 83%, wide working temperature range -40 to +100C, 2KV I/P-O/P isolation voltage, compliance to BS EN/EN55032. The models account for different input voltage 5V/12V/24V±10%, and various output voltage, 5V/12V/15V for single output which are suitable for all kinds of systems such as industrial control, telecommunication field, distributed power architecture, and more.

Operating conditions

Minimum Operating Temperature:-40°C

Maximum Operating Temperature:90°C

Input

Input Frequency:N/A

Output

Output Current:0.056 A

Output Voltage:18 VDC

Additional Output Voltages (VDC):N/A

Features

AC Power Cord:N/A

Power Rating:1 W
