Single Output Moisture-Proof Adapter Euro Plug Input 90-264VAC XLR 4P Output 24V 3.75A

Features

  • Universal AC Input / Full range
  • Class II power unit, no FG
  • Built-in active PFC
  • High efficiency up to 91%
  • No load power consumption <0.15W
  • Energy efficiency Level VI
  • Comply with EU ErP
  • Meets CoC Version 5
  • Fanless design, cooling by free air convection
  • Protections: short circuit, overload, over voltage, over temperature
  • 5-year warranty

Overview

The OWA-90E series is a 90W AC/DC, class II (no earth pin) external power supply series pinpointing the moisture proof feature. The fully potted silicone inside the plastic enclosure enhances the head dissipation; it also benefits the power body of OWA-90E to achieve IP67 level, so the series specializes in the applications in which the damp, humidity or dust resistance is needed for the external power supply. OWA-90E follows the latest energy efficiency demand, and is compliant with EU ErP and meets Code of Conduct (CoC) Version 5 (except for 12V); the no load power consumption less than 150mW. It is certified with EN61558-2-16; moreover, the compliance to EN60335-1 for selected models can greatly simplify the system such a household appliances.

Applications

  • Robotic lawn mower
  • Household appliances
  • Battery charging
  • General electronic products in dusty or humid environment

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:OWA-90E

Compliance

Agency Approvals: CE, EAC, EN, TUV

Dimensions & Appearance

Style:Desktop
Color:Black
Height:1.48 in.
Width:2.48 in.
Length:6.73 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:0.95 A

Output

Number of Outputs:1
Output Connector Type:XLR 4P
Output Connector Diameters:N/A
Output Voltage (Channel 1):24 VDC
Output Voltage:24 VDC
Output Current (Channel 1):3.75 A
Additional Output Voltages (VDC):N/A
Output Current:3.75 A

Features

AC Power Cord:Euro Plug CEE 7/7
Minimum Isolation Voltage:3750V
Polarity:N/A
Product Note:Level VI
IP Rating:N/A
Efficiency:90%
Power Rating:90 W
,
