Single Output Industrial AC-to-DC Switching Power Supply 42 Volts 14.3 Amps 600.6 Watts

42 Volts @ 14.3 Amps

Specifications

  • Output Power (W): 600.6
  • Ripple & Noise (mV p-p): 250
  • Load Regulation (±): 0.5%
  • Line Regulation (±): 0.5%
  • Efficiency: 96%
  • Size (L x W x H) inches: 11 X 5.6 X 1.9
  • Universal AC input / Full range
  • Built-in active PFC function
  • Protections: short circuit, over voltage, over current
  • Output voltage and output current can be adjusted through internal potentiometer
  • Fanless design, cooling by free air convection
  • LED indicator for power on
  • 5 year warranty

    • Product Identification

    Type:Auto Switching SMPS
    Manufacturer Series:HEP-600

    Compliance

    Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

    Dimensions & Appearance

    Style:Enclosed
    Color:Silver
    Height:1.9 in.
    Length:11 in.
    Width:5.7 in.

    Operating conditions

    Minimum Operating Temperature:-40°C
    Maximum Operating Temperature:70°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Input Voltage:90 VAC to 264 VAC
    Maximum Input Current:7 A

    Output

    Number of Outputs:1
    Output Voltage (Channel 1):42 VDC
    Output Connector Type:Screw Terminal Block
    Output Voltage:42 VDC
    Output Current (Channel 1):14.3 A
    Output Current:14.30 A

    Features

    PFC Function:Yes
    Minimum Isolation Voltage:3000V
    Efficiency:96%
    Power Rating:600.6 W
    ,
