Rocker Switch SPST-NO OFF-(ON) 16A 125VAC Panel Mount Snap-In

Specifications

  • Circuit: SPST-NO
  • Switch Function: OFF-Momentary ON, OFF-(ON), OFF-MOM
  • Rating: 16A @ 125VAC, 10A @ 250VAC
  • Actuator Type: Concave (Curved)
  • Color - Actuator/Cap: Black
  • Actuator Marking: Power Symbol
  • Mounting Type: Panel Mount, Snap-In
  • Termination Style: Quick Connect - 0.187" (4.7mm)
  • Ingress Protection: Dust Proof
  • Panel Cutout Dimensions: Rectangular - 19.20mm x 13.00mm
  • Operating Temperature: -20°C to 85°C
  • Mechanical Life: 100,000 Cycles
  • Electrical Life: 6,000 Cycles

Product Identification

Product Type:Rocker Switch

Dimensions & Appearance

Mounting Style:Panel Mount
Depth:0.444 in.
Height:0.896 in.
Width:0.584 in.
Length:0.845 in.
Body Color:Black

Features

Pins:2
Termination Style:0.187" Quick Connect
Color - Actuator/Cap:Black
UL Flammability Code:94V-2
Switch Function:OFF-(ON)
Illumination Type:None
Actuator Length:0.145 in.
IP Rating:none
Contact Form:SPST-NO
Actuator Type:Rocker
Current Rating:16A @ 125VAC, 10A @ 250VAC
,
