RF Demo Kit (Receiver)

Features

• Energized by USB.
• Connected with PC for control through software.
• When connected with DSG3000, it can be controlled via the built-in control interface of DSG3000 without using the PC.
• The frequency of the DSG3000 output signal is converted to the down-frequency by “switches”. The down-frequency signal can be connected to the input port of the spectrum analyzer or the oscilloscope to be used for the learning, operation and demonstration.
• Provide 10 MHz reference signal output for easy clock synchronization with other devices.
• Provide 500 MHz and 1 GHz local oscillator signal outputs.
• Modular circuit design; provide interfaces for users to make separate measurement of any component; enable to replace any component.

Overview

RX1000 RF Demo Kit is a signal receiver kit released by RIGOL to demonstrate the DSG3000 series RF signal generator.
