Reliable DC-DC Converter PC-Mount for Railway Applications 60W 5V 12A Output 40-160V Input

Features

• Compliance with EN50155 railway standard
• 2"x1" compact size with low profile (10.5mm high)
• 4:1 wide input range
• Wide operating temperature range: -40°C to +85°C
• No minimum load required
• Fully encapsulated
• Protections: Short circuit (continuous), overload, over voltage, over temperature, input under voltage lock-out
• 3000 VDC isolation voltage
• Remote ON/OFF control
• 3-year warranty

Overview

RSDW60 series are 60W module type DC-DC reliable railway converters in a 2"x1" package. It features international standard pins, a high-efficiency up to 92%, wide working temperature range of -40°C to +85°C, 3000 VDC I/P-O/P isolation voltage, compliance with EN50155 railway standard, continuous-mode short circuit protection, and more. The 4:1 wide input range is different by model, 9V to 36V (F model), 18V to 75V (G model), and 40V to 160V (H model). The power supply converter is suitable for railway, trams, buses and can be used in harsh environments with high vibration, high dust, extremely low or high temperatures.

Applications

• Bus, tram metro or railway system
• Telecom/datacom system
• Wireless network
• Industrial control facility
• Instrument
• Analyzer
• Highly vibrating, heavily dusty, extremely low or high temperature harsh environments
