Regulated DC-DC Converter ±15V ±190mA 6W 18-36Vin DIP-24 Pi Input Filter

Features

  • 5-6W Isolated Output
  • 24-Pin DIP Package
  • Efficiency to 84%
  • 2:1 Input Range
  • Regulated Outputs
  • Pi Input Filter
  • 1500VDC Isolation
  • Continuous Short Circuit Protection
  • UL60950-1 Approval
  • Safety Meets IEC/EN/UL 62368-1

Overview

Regulated DC-DC Converter ±15V ±190mA 6W 18-36Vin DIP-24 Pi Input Filter.

Product Identification

Type:Isolated
Additional Feature:Pi Input Filter
Product Type:DC-DC Converter SMPS
Manufacturer Series:EC4A

Compliance

Agency Approvals:UL, CUL, CE

Dimensions & Appearance

Color:Black
Height:0.40 in.
Width:0.80 in.
Length:1.25 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:71°C

Input

Input Frequency:N/A
Input Voltage:24 VDC
Input Voltage Range:18 VDC to 36 VDC
Maximum Input Current:0.293 A

Output

Number of Outputs:2
Output Current:±0.19 A
Additional Output Voltages (VDC):-15 VDC
Output Connector Type:PC Pins
Output Voltage:15 VDC

Features

Isolation Voltage:1500VDC
Pins:10
AC Power Cord:N/A
Efficiency:81%
Power Rating:6 W
,
