Regulated DC-DC Converter 5V 8A 40W 9-36Vin 6-Side Shield

Features

  • 40W Isolated Output
  • Efficiency to 91%
  • 2.05"x1.2x0.4" Six-Sided Shield Metal Case
  • 4:1 Input Range
  • Regulated Outputs
  • Fixed Switching Frequency
  • Low No Load Power Consumption
  • Input Under Voltage Protection
  • Over Current Protection
  • Remote On/Off
  • Continuous Short Circuit Protection
  • No Tantalum Capacitor Inside
  • Safety Meets IEC/EN/UL 62368-1

Overview

Regulated DC-DC Converter 5V 8A 40W 9-36Vin 6-Side Shield.

Product Identification

Manufacturer Series:ECLB40W
Additional Feature:Remote ON/OFF, No Tantalum Capacitors Inside
Product Type:Isolated DC-DC Converter SMPS

Compliance

Agency Approvals:CE

Dimensions & Appearance

Mounting:PCB
Height:0.40 in.
Color:Silver
Width:1.20 in.
Length:2.05 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Packaging

Package:Quarter Brick

Input

Input Voltage Range:9 VDC to 36 VDC
Input Voltage:24 VDC
Maximum Input Current:1.842 A

Output

Number of Outputs:1
Output Voltage:5 VDC
Output Connector Type:PC Pins
Output Current:8 A

Features

Pins:6
AC Power Cord:N/A
Efficiency:90.5%
Power Rating:40 W
,
