Regulated DC-DC Converter 5V 400mA 2W 4.5-9Vin 1500V Isolation SIP-8

Features

  • 2W Isolated Output
  • Compact SIP-8 Package
  • Efficiency to 84%
  • 2:1 Input Range
  • Regulated Outputs
  • Remote On/Off Control
  • 1500VDC Isolation
  • Continuous Short Circuit Protection
  • Under Voltage Protection
  • Safety Meets IEC/EN/UL 62368-1

Overview

Regulated DC-DC Converter 5V 400mA 2W 4.5-9Vin 1500V Isolation SIP-8.

Product Identification

Type:Isolated
Manufacturer Series:EC2SA
Product Type:DC-DC Converter Regulated Outputs Wide Input
Additional Feature:Meets IEC/EN/UL 62368-1

Compliance

Agency Approvals:CE

Dimensions & Appearance

Color:Black
Height:0.44 in.
Width:0.36 in.
Length:0.86 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Input

Input Frequency:N/A
Input Voltage Range:4.5 VDC to 9 VDC
Input Voltage:5 VDC
Maximum Input Current:0.526 A

Output

Number of Outputs:1
Output Voltage:5 VDC
Output Connector Type:PC Pins
Output Current:0.40 A
Additional Output Voltages (VDC):N/A

Features

Isolation Voltage:1500VDC
Pins:7
AC Power Cord:N/A
Efficiency:76%
Power Rating:2 W
,
