Regulated DC-DC Converter 12V 2.5A 30W 9-36Vin 2x1" 6-Side Shield

Features

  • 30W Isolated Output
  • Efficiency to 92%
  • 2"x1" Six-Sided Shield Metal Case
  • 4:1 Input Range
  • Regulated Outputs
  • Fixed Switching Frequency
  • Input Under Voltage Protection
  • Over Current Protection
  • Remote On/Off
  • Continuous Short Circuit Protection
  • No Tantalum Capacitor Inside
  • Safety Meets IEC/EN/UL 62368-1

Overview

Regulated DC-DC Converter 12V 2.5A 30W 9-36Vin 2x1" 6-Side Shield.

Product Identification

Type:Isolated
Additional Feature:No Tantalum Capacitors Inside, Remote ON/OFF
Product Type:DC-DC Converter SMPS
Manufacturer Series:EC9BW

Compliance

Agency Approvals:CE

Dimensions & Appearance

Color:Black
Height:0.40 in.
Width:1 in.
Length:2 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Input

Input Frequency:N/A
Input Voltage Range:9 VDC to 36 VDC
Input Voltage:24 VDC
Maximum Input Current:1.374 A

Output

Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:PC Pins
Additional Output Voltages (VDC):N/A
Output Current:2.50 A

Features

Isolation Voltage:1500VDC
Pins:6
AC Power Cord:N/A
Efficiency:91%
Power Rating:30 W
,
