Railway Isolated DC-DC Converter 150W 15V 10A Out 12-160Vin Negative Logic Remote On-Off M3 Mounting Inserts

Features

  • 150W Isolated Output
  • Efficiency up to 90.5%
  • Fixed Switching Frequency
  • 14:1 Input Range
  • Regulated Outputs
  • Negative Logic Remote On/Off
  • Low No Load Power Consumption
  • Fully protected (OTP/OCP/OVP/UVLO)
  • 3000Vac I/O Isolation
  • Operating Case Temperature -40 to +105°C
  • Quarter Brick Size Meet Industrial Standard 2.28" x 1.45" x 0.5"
  • CB Test Certificate IEC62368-1
  • EN55032/EN55035/EN50155 Compliant with External Circuits
  • UL62368-1 2nd (Reinforce Insulation) Approval
  • Shock & Vibration EN50155 (EN61373) Compliant
  • Fire & Smoke EN45545-2 Compliant
  • 5000m Operating Altitude
  • M3x0.5 Mounting Inserts

Overview

Railway Isolated DC-DC Converter 150W 15V 10A Out 12-160Vin Negative Logic Remote On-Off M3 Mounting Inserts.

Product Identification

Type:Isolated
Additional Feature:Negative Logic Remote ON/OFF
Product Type:DC-DC Converter for Railway SMPS
Manufacturer Series:CQB150W14

Compliance

Agency Approvals:UL, CUL, CB, CE, EN, UKCA

Dimensions & Appearance

Color:Black, Gray
Height:0.50 in.
Width:1.45 in.
Length:2.28 in.

Operating conditions

Maximum Operating Temperature:105°C
Minimum Operating Temperature:-40°C

Input

Input Voltage Range:12 VDC to 160 VDC
Input Voltage:72 VDC
Maximum Input Current:12.5 A

Output

Number of Outputs:1
Output Connector Type:PC Pins
Output Voltage:15 VDC
Additional Output Voltages (VDC):N/A
Output Current:10 A

Features

Isolation Voltage:3000V
Pins:10
AC Power Cord:N/A
Efficiency:90.5%
Power Rating:150 W
,
