@PWR SPLY,SW,ENCL,[email protected],50W,90-264VAC,89%,UL/CE,SCW TERM
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:YEL50
Compliance
Agency Approvals:CE, UKCA, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Height:1.18 in.
Width:3.23 in.
Length:3.90 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:0.95 A
Output
Number of Outputs:1
Output Current (Channel 1):1.45 A
Output Voltage (Channel 1):36 VDC
Output Connector Type:Screw Terminal Block
Output Voltage:36 VDC
Output Current:1.45 A
Features
PFC Function:No
Minimum Isolation Voltage:4000V
Efficiency:89%
Power Rating:52 W
