PWR SPLY,SW,DIN,120W,12V@10A,85-264VAC,OVC3,4KVAC ISOL
Product Identification
Product Type:Economical Ultra-Slim Industrial DIN Rail Power Supply
Manufacturer Series:XDR-120E
Compliance
Agency Approvals: CB, CCC, CE, C-TICK, CUL, EAC, EN, IS, KC, TUV, UKCA, UL
Dimensions & Appearance
Color: Silver, Black
Depth:4.75 in.
Width:1.23 in.
Height:5.13 in.
Operating conditions
Minimum Operating Temperature:-40°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:2.25 A
Output
Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Output Current:10 A
Features
PFC Function:No
Low Power Source (LPS):No
Minimum Isolation Voltage:4000VAC
Efficiency:89%
Power Rating:120 W
