3000W AC/DC Enclosed Switching Power Supply 48V 62.5A
48 Volts DC @ 62.5 AmpsSpecifications
- Size (L x W x H) (inches): 10.9 x 7.0 x 2.5
- Ripple and Noise (mV p-p): 200
- Load Regulation: 0.5%
- Line Regulation: 0.5%
- Input: 180-264VAC @ 47-63Hz, or 254-370VDC
- Built-in active Power Factor Correction function
- 3-year warranty
- Certifications: UL/CUL/TUV/CE/CB/PFC
Overview
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:RSP-3000
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Length:10.9 in.
Height:2.5 in.
Width:7 in.
Operating conditions
Minimum Operating Temperature:-20°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:180 VAC to 264 VAC
Maximum Input Current:20 A
Output
Number of Outputs:1
Output Voltage (Channel 1):48 VDC
Output Connector Type:Lug Terminal Female
Output Voltage:48 VDC
Output Current (Channel 1):62.5 A
Output Current:62.50 A
Features
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:90.5%
Power Rating:3000 W
