Power Supply DIN Rail 85-264VAC Input 48VDC Output 120W 2.5A Compact PFC

Features

  • High efficiency 91% and low power dissipation
  • 150% peak load capability
  • Built-in active PFC function, PF>0.93
  • Protections: Short Circuit / Overload / Over Voltage / Over temperature
  • Cooling by free air convection
  • DIN rail mountable
  • UL 508 (industrial control equipment) approved
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • Built-in DC OK relay contact
  • 100% full load burn-in test
  • 3 year warranty

Overview

Power Supply DIN Rail 85-264VAC Input 48VDC Output 120W 2.5A Compact PFC

Product Identification

Product Type:Compact Housing Single Phase DIN Rail Power Supply
Manufacturer Series:PS-C120

Compliance

Agency Approvals: SEMI F47, CB, CE, CUL, EN, GL, UL

Dimensions & Appearance

Color:Silver
Depth:4.47 in.
Width:1.57 in.
Height:4.93 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:1.4 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):48 to 55
Output Current:2.50 A

Features

Low Power Source (LPS):No
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:90.5%
Power Rating:120 W
,
