Power Supply DIN Rail 85-264VAC Input 24VDC Output 100W 4.2A

Features

  • Universal AC input / full range
  • Protections: Short Circuit / Overload / Overvoltage / Over temperature
  • ZCS/ZVS technology to reduce power dissipation
  • Cooling by free air convection
  • DIN rail mountable
  • DC OK relay contact
  • No load power consumption < 1W
  • LED indicator for power on
  • 100% full load burn-in test
  • 3-year warranty

Overview

Power Supply DIN Rail 85-264VAC Input 24VDC Output 100W 4.2A

Product Identification

Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:PSS100

Compliance

Agency Approvals: CE, CUL, EN, UL

Dimensions & Appearance

Color:White
Depth:3.94 in.
Width:2.17 in.
Height:3.54 in.

Operating conditions

Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:1.3 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Additional Output Voltages (VDC):24 to 30
Output Current:4.20 A

Features

Low Power Source (LPS):No
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:86%
Power Rating:100 W
,
