Power Supply DIN Rail 85-264VAC Input 15VDC Output 90W 6.5A Univ

Features

  • Universal AC input / full range
  • Protections: Short Circuit / Overload / Over Voltage / Overtemperature
  • Cooling by free air convection
  • DIN rail mountable
  • Isolation class II
  • LED indicator for power on
  • No load power consumption <1W
  • 100% full load burn-in test
  • 3 year warranty

Overview

Power Supply DIN Rail 85-264VAC Input 15VDC Output 90W 6.5A Univ

Product Identification

Product Type:Low Profile Single Phase DIN Rail Power Supply
Manufacturer Series:PS-100

Compliance

Agency Approvals: CE, CUL, EN, UL

Dimensions & Appearance

Depth:2.20 in.
Color:White
Height:3.66 in.
Width:3.94 in.

Operating conditions

Minimum Operating Temperature:-20°C
Maximum Operating Temperature:60°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:3 A

Output

Number of Outputs:1
Additional Output Voltages (VDC):15 to 18
Output Voltage:15 VDC
Output Connector Type:Screw Terminal Block
Output Current:6.50 A

Features

PFC Function:No
Low Power Source (LPS):No
Minimum Isolation Voltage:3000V
Efficiency:87%
Power Rating:90 W
,
