Power Supply DIN Rail 85-264VAC Input 12VDC Output 120W 10A

Features

  • Universal AC input range (90 to 264Vac)
  • High efficiency up to 89%
  • Built-in current limiting circuit
  • Output protections: OVP/OLP/SCP/OTP
  • Wide operating ambient temp (-20°C to 70°C)
  • Built-in DC OK function (indication only)
  • Can be installed on TS-35/7.5 or TS-35/15
  • 100% full load burn-in test
  • Suitable for critical applications
  • Operating altitude up to 6000m
  • PCB with conformal coating
  • Ultra-slim, 45mm width
  • 3 years warranty

Overview

Power Supply DIN Rail 85-264VAC Input 12VDC Output 120W 10A

Product Identification

Product Type:Ultra-Compact Single Phase DIN Rail Power Supply
Manufacturer Series:PSC-U120

Compliance

Agency Approvals: CB, CE, CUL, EN, UKCA, UL

Dimensions & Appearance

Color:Gray
Depth:4.69 in.
Width:1.77 in.
Height:4.88 in.

Operating conditions

Minimum Operating Temperature:-20°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:2.7 A

Output

Number of Outputs:1
Additional Output Voltages (VDC):12 to 14
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Output Current:10 A

Features

PFC Function:No
Low Power Source (LPS):No
Minimum Isolation Voltage:3000V
Efficiency:85%
Power Rating:120 W
,
