50W Single Output DC-DC Converter


5 Volts @ 10 Amps

Features:
  • 2:1 wide input range
  • Protections: Short circuit / Overload / Over voltage
  • 1500VAC I/O isolation
  • Built-in EMI filter, low ripple noise
  • 100% full load burn-in test
  • Fixed switching frequency at 83KHz
  • Low cost
  • High reliability
  • 2 years warranty

Product Identification

Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-50

Compliance

Agency Approvals: EAC, EN, CE, CE, EN, EAC

Dimensions & Appearance

Mounting:Enclosed
Height:1.5 in.
Width:3.8 in.
Length:6.3 in.

Operating conditions

Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C

Packaging

Package:Enclosed

Input

Input Voltage:24 VDC
Input Voltage Range:19 VDC to 36 VDC
Maximum Input Current:3 A

Output

Number of Outputs:1
Output Voltage:5 VDC
Output Connector Type:Screw Terminal Block
Additional Output Voltages (VDC):N/A
Output Current:10 A

Features

Pins:5
Switching Regulator:Yes
Efficiency:73%
Power Rating:50 W
,
