Isolated Encapsulated DC-to-DC Converter
SKE15 Series: Single Output

Available in both single and dual outputs, the Mean Well SKE15 series are very popular regulated 15-watt DC-to-DC converters because of their low-cost, reliability, and industry-standard package comprised of a six-sided, shielded metal case. The input-to-output isolation is an impressive 1000VDC, with I/O isolation resistance of 100Mohm. Continuous short-circuit protection and overload protection, both with auto-recovery, are standard features. The input voltage range is a wide 2:1 and electrical noise is minimized with a pi-network input filter.

• 1000VDC isolation
• Input filter: Pi-network
• Protection: short-circuit & overload
• Industry standard package
• 2:1 wide input range
• Free-air convection cooling
• 100% burn-in test
• One-year warranty
• Shielded metal case
• Working temperature: -15° to +60°C @ full load; -25° to +71°C @ 80% load
• Input range: 36-72V
• Output voltage: +5V @ 3000mA
• Power: 15.0W
• Power density: 9.4W/in3
• Pins: 5
• Ripple & noise: 50mV p-p
• Line Reg.:  0.3%
• Load Reg.:  0.5%
• Switching frequency (Hz) min.: 150k
• Isolation voltage: 1000
• Temperature: -15° to +60°C
• Efficiency: 80%
• Weight: 0.15 lbs.
