10W DC-DC Regulated Single Output Converter
15 Volts @ 66.6- 666 Milliamps
Features:
- 2:1 wide input range
- 1000VDC I/O isolation
- Built-in EMI filter
- Protections: Short circuit / Overload
- Cooling by free air convection
- Six-sided shield metal case
- 100% burn-in test
- Low cost / High reliability
- Approvals: FCC / CE
- 2 years warranty
Product Identification
Product Type:DC to DC Converter and Switching Regulator Module SMPS
Manufacturer Series:SKE10
Dimensions & Appearance
Height:0.44 in.
Width:1 in.
Length:2 in.
Operating conditions
Minimum Operating Temperature:-25°C
Maximum Operating Temperature:71°C
Input
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC
Output
Number of Outputs:1
Output Voltage:15 VDC
Additional Output Voltages (VDC):N/A
Output Current:0.666 A
Features
Pins:5
Power Rating:10 W
