Isolated Encapsulated DC-to-DC Converter
SKE10 Series: Single Output

The Mean Well SKE10 family of regulated DC-to-DC converters include popular single and dual-output 10-watt configurations packaged in six-sided shielded metal cases. The industry-standard package size supports full power with free-air convection. Performance features include a wide input voltage range of 2:1 and the use of a pi-network input filter for low noise operation. The input-to-output isolation is an impressive 1000VDC, with I/O isolation resistance of 100MΩ. Line regulation is  0.3% maximum, and load regulation for a load change of 20% to full load is  1% for single output and  2% for dual output. The working temperature is 15°C to +60°C with no derating and 25°C to +71°C at 80% load. Protection includes short-circuit and overload.

• 1000VDC isolation
• Input filter: Pi-network
• Protection: short-circuit & overload
• Industry standard package
• 2:1 wide input range
• Free-air convection cooling
• No external components needed
• 100% burn-in test
• One-year warranty
• Very high MTBF
• Working temperature: -15° to +60°C @ full load; -25° to +71°C @ 80% load
• Input range: 9-18V
• Output voltage: +12V @ 840mA
• Power: 10.0W
• Power density: 12.5W/in3
• Pins: 5
• Ripple & noise: 50mV p-p
• Line Reg.:  0.3%
• Load Reg.:  01.0%
• Switching frequency (Hz) min.: 300k
• Isolation voltage: 500
• Temperature: -15° to +60°C
• Efficiency: 81%
• Weight: 0.07 lbs.
