Power Relay 40A 24VDC Solid State Panel Mount 90VAC 12 VDC (Nom.)

Features

  • Product Type: Power Relays
  • Harmonized Code: 8538.90.9000
  • ECCN: EAR99
  • Series: SE
  • Mounting Type: Chassis Mount
  • Coil Voltage: 12 VDC
  • Contact Form: SPDT (1 Form C)
  • Contact Rating (Current): 40 A
  • Switching Voltage: 600VDC - Max
  • Load - Max Switching: 24000W
  • Coil Current: 171.4 mA
  • Coil Type: Non Latching
  • Features: N/A
  • Termination Style: Screw Terminal
  • Seal Rating: N/A
  • Coil Insulation: N/A
  • Must Operate Voltage: 10.2 VDC
  • Must Release Voltage: 1.2 VDC
  • Operate Time: N/A
  • Release Time: N/A
  • Operating Temperature: -55°C ~ 55°C
  • Contact Material: Silver Alloy
  • Approval Agency: CE, CSA, cULus
  • Relay Type: General Purpose
  • Grade: N/A
  • Qualification: N/A

Overview

Power Relay, 40A, 24VDC, Solid State, Panel Mount, 90VAC, 12 VDC (Nom.).

Product Identification

Additional Feature:N/A
Product Type:General Purpose
Manufacturer Series:SE

Compliance

Agency Approvals: CSA, CUL, UL, CE

Dimensions & Appearance

Mounting:Chassis Mount

Operating conditions

Minimum Operating Temperature:-55°C
Maximum Operating Temperature:55°C

Features

Relay Construction:Non Latching
Coil Voltage:12 VDC
Contact Form:SPDT (1 Form C)
Control Voltage:600 VDC - Max
Contact Material:Silver Alloy
Contact Rating:40 A
Termination:Screw Terminal
,
