Piezo Buzzer
Electrical Specifications:
- Rated Voltage: 5Vp-p
- Rated Current: 5mA (max)
- Sound Output At 10cm: 80 dBA(min)
- Resonant Frequency: 4000Hz ± 500
- Capacitance: 13000pF ± 30%
- 7.2 Ohm
Dimensions & Appearance
Diameter:0.54 in.
Height:0.27 in.
Size (H" x Dia."):0.27 x 0.54
Mounting:Through Hole
Operating conditions
Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C
Input
Input Voltage:3 V
Output
Output:73 dBA
Features
Voltage Range (Vp-p):0-5
Technology:Mechanical
Tone Mode:Transducer/Speaker
Termination Style:PC Pins
Frequency:4000 Hz
Frequency Range:500 Hz to 4000 Hz
Current Rating:14 mA
