PCB Terminal Block 3.50mm 8 Pole Front Wire Green 12A 300V 16-30AWG 12.6mm Height Modular
Features
- Product Type: Terminal Block
Overview
PCB Terminal Block 3.50mm 8 Pole Front Wire Green 12A 300V 16-30AWG 12.6mm Height Modular
Product Identification
Manufacturer Series:MVS-13
Dimensions & Appearance
Length:28 mm
Mounting:Through Hole
Body Orientation:Horizontal
Operating conditions
Maximum Operating Temperature:105°C
Features
Number of Rows:1
Number of Positions:8
Housing Color:Green
Pitch:0.138 in., 3.5 mm
Bottom Termination:PC Pins
Top Termination:Screw Cage
Gender:Female
Housing Material:Polyamide
Contact Plating:Tin
Contact Material:Steel
Wire Gauge (AWG):16-30
Description:Terminal Block
Voltage Rating:300 VAC
Current Rating:10 A
