50W Triple Output Medical Type

Channel 1: 5 Volts @ 4 Amps
Channel 2: 15 Volts @ 1.5 Amps
Channel 3: -15 Volts @ 0.5 Amps

Features:

  • 4" x 2" miniature size
  • Universal AC input / Full range
  • Low leakage current <150uA
  • Protections: Short circuit / Overload / Over voltage
  • Cooling by free air convection
  • ANSI/AAMI ES60601-1 and IEC/BS EN/EN60601-1 medical safety approved
  • Medical safety approved (2xMOPP) suitable for BF applications with appropriate system considerations
  • 3-year warranty

Specifications

  • Channel 1 Output: 5V @ 4A (0.5A-4.4A)
  • Channel 2: 15V @ 1.5A (0.1A-1.65A)
  • Channel 3: -15V @ 0.5A (0.1A-0.55A)
  • Rated Power: 50W
  • Peak Load (10 sec.): 55 W

Applications

  • Oral irrigator
  • Hemodialysis machine
  • Medical computer monitors
  • Sleep apnea devices

Product Identification

Type:Auto Switching SMPS
Product Type:AC to DC Power Supply SMPS
Manufacturer Series:RPT-60

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL

Dimensions & Appearance

Style:Medical Open Frame
Height:1.1 in.
Width:2 in.
Length:4 in.

Operating conditions

Minimum Operating Temperature:-20°C
Maximum Operating Temperature:65°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:1.1 A

Output

Number of Outputs:3
Output Connector Type:JST B6P-VH or equiv.
Output Connector Diameters:N/A
Output Voltage:5 VDC
Additional Output Voltages (VDC): -15 VDC, 15 VDC
Output Current:4.40 A

Features

Minimum Isolation Voltage:4000V
Efficiency:79%
Power Rating:55 W
,
