Modified Sine Wave DC-AC Power Inverter 1500W 110VAC Output 3xUSA Receptacle 12VDC 170A Ring Terminal Input

Jameco Part #:

Manufacturer #:

Non Cancelable

Non Returnable

Product Price:

$323.950

In Stock: 0

Quantity	Unit Price	You Save	Discount
1+	$323.950	-	-
5+	$303.950	20.00	6.17%
25+	$288.950	35.00	10.8%

12V or 24V DC input (depending on the model)
Power ON-OFF switch
Input voltage range: -15% to +25%
Output voltage regulation: ±10%
Protections: Input reverse polarity, battery low alarm, batterl low shutdown, over voltage, over load, over temperature, output short
Output waveform: Modified sine wave
Cooling fan ON-OFF control
ON/OFF remote control (optional/order no: RC-1700)
Approvals: E13, EAC, CE, UKCA
1 year warranty

Product Identification

Product Type:Modified Sine Wave DC-AC Power Inverter

Manufacturer Series:A301-1K7

Agency Approvals:CE, EN, EAC, UKCA, E13

Color:Silver

Height:3.35 in.

Length:17.91 in.

Width:8.27 in.

Mounting:Chassis

Minimum Operating Temperature:0°C

Maximum Operating Temperature:30°C

Input Frequency:N/A

Input Voltage:12 VDC

Input Voltage Range:10 VDC to 16.5 VDC

Maximum Input Current:170 A

Number of Outputs:3

Output Connector Type:NEMA 5-15R x3

Output Voltage:110 VAC

Output Current:N/A

AC Power Cord:NOT INCLUDED

Efficiency:82%

Power Rating:1500 W
