MCC USB-ERB08: 8 Channel Electromechanical Relay USB Device

Please Note: Due to EU regulations, we are unable to ship the MCC USB-ERB08 and USB-ERB24 to EU countries.

Digilent is now a proud distributor of Measurement Computing Corporation (MCC) DAQ and data logging products. MCC is a leading supplier of data acquisition solutions that are easy-to-use, easy-to-integrate, and easy-to-support.

The USB-ERB Series 8 channel relay interface devices provide support for Form C electromechanical relays. Each device is designed with a heavy-duty chassis for rugged DAQ applications.

Software support includes QuickDAQ, an out-of-the-box application for data logging, visualization, and signal generation. Two QuickDAQ upgrades are available and offer FFT analysis functions. Drivers are included for the most popular applications and programming languages including Visual C++®, Visual C#®, Visual Basic®.NET, DASYLab®, LabVIEW™, MATLAB®, and Python™.

Features

• Eight single-pole double-throw (SPDT) Form C electromechanical relays directly controlled by digital I/O lines.
• Supports configurations as two banks of four.
• Onboard switches to configure the logic polarity (active high or low) and power-on state for each relay group.
• Switch settings can be read back with software.
• Screw terminals for field wiring connections with three connections to each relay ? normally open (NO), normally closed (NC), and common (C).
• USB out and power out connections support powering and controlling multiple MCC USB devices that support daisy-chaining from one external power source and one USB port in a daisy-chain configuration.
• Rugged enclosure that can mount on a DIN rail or on a bench
• The USB-ERB08 is powered by an external 9 V regulated power supply, which is included.

What's Included

• USB-ERB08
• USB cable
• 9 V power supply
• Printed insert: DAQami Quick Start
• MCC packaging assembly/foam, etc.

Downloads & Resources

Prioritizing on ease of use and flexibility, MCC offers out-of-the-box software plus drivers for the most popular programming languages and applications. For a full-featured and customizable experience, DASYLab® provides real-time analysis and control, plus the ability to create custom applications without programming. DASYLab can be purchased directly from MCC. For maximum customization, drivers are included for Visual C++®, Visual C#®, Visual Basic®.NET, LabVIEW™, and Python™.

• MCC Knowledgebase
• MCC DAQ Software
