LMXX-Compatible SIP-3 Non-Isolated DC-DC Converter 15V 1A

Features

  • Efficiency Up to 95%
  • Regulated Outputs
  • Fully Protected (OCP/OTP/UVLO)
  • Operating Ambient Temperature -40 to +105°C
  • 0.48”x0.34”x0.69” Size Pin Compatible with LMxx Linear Regulators (SIP-3)
  • EN 55032 Compliant with External Circuits
  • Safety Meets IEC/EN/UL 62368-1

Overview

LMXX-Compatible SIP-3 Non-Isolated DC-DC Converter 15V 1A.

Product Identification

Product Type:Non-Isolated DC-DC Converter
Manufacturer Series:NCS01W8

Compliance

Agency Approvals:CE, EN, UKCA

Dimensions & Appearance

Style:Encapsulated
Color:Black
Length:0.48 in.
Width:0.34 in.
Height:0.69 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Input

Input Voltage:24 VDC, 48 VDC
Input Voltage Range:18 VDC to 72 VDC
Maximum Input Current:0.34 A

Output

Number of Outputs:1
Output Connector Type:PC Pins
Output Voltage:15 VDC
Output Current:1 A

Features

Pins:5
Lead Style:Vertical
Efficiency:94%, 92%
Power Rating:15 W
,
